CellarCool AL1: the cellar has fallen below the low alarm limit
AL1 uses the same margin as AH1 on each CellarCool series, just below the setpoint instead of above.
Mon–Sat, 8am–8pm
- Temperature and alarms
- Cellar cooling load and room check
- Source: CellarCool
Book a visit
Three short steps, about a minute.
or call (844) 398-5977
Loading appointment form…
The appointment form couldn’t load. Please try again.
What AL1
actually means.
AL1 uses the same margin as AH1 on each CellarCool series, just below the setpoint instead of above. CellarCool's first check is whether the unit is still cooling: if the snowflake is lit, the unit is overshooting; if not, the cellar is losing heat to a cold space and needs warming from outside the unit.
CellarCool wine cellar cooling unit display · also shown as “AL1”
What to do when AL1 shows on the wine cellar cooling unitKind of codeTemperature and alarms
The controller saw the cellar go past a high or low limit and raised an alarm, sometimes holding the worst reading it logged while the house was empty. The reason can be as small as the cellar door left ajar after a tasting or a long outage, a room gaining heat from new lights or a sunny glass wall, or as serious as cooling that has stopped. Keep the door shut and read a thermometer on a middle rack before touching anything; the alarm is a warning about the collection, not yet a diagnosis.
Usually leads toCellar cooling load and room check
Measuring the cellar as the cooling unit sees it: insulation, vapor barrier, door, glass and the heat load, to show whether the unit can ever keep up.
Shows up asWine Cellar Too Cold
A wine cellar too cold feels like stepping into a walk-in: the thermometer sits in the 40s, bottles come out beaded with water, and the unit keeps running long after the room should have been satisfied.
MakeCellarCool
Service for CellarCool systems when the wine room drifts warm, turns dry or the unit starts and stops every few minutes.
SourceCellarCool CM2500 (Ceiling Mount split) manual, version 4 (02/2022)
Both CellarCool controller types: the CX through-the-wall controller and the digital controller on Ceiling Mount, split and Ultimate models.
Before you book,
in this order.
Each step comes from CellarCool's own guidance for AL1 on its wine cellar cooling units. Follow it to the end: the last card says whether this is a visit.
Look for the snowflake on the display; if it is lit while the cellar is already cold, switch the unit off and book a visit.
If the unit is idle, warm the room gently until the wine returns to the setpoint.
Check the probe against a known thermometer; CellarCool's digital controller manuals include a probe calibration check in the user menu.
Still there?
It usually turns into cellar cooling load and room check. Book with the code and the model number.
What not to do
AL1 alone does not mean refrigerant or compressor trouble. In winter it is often just the cellar's surroundings.
What you may
notice with it.
The wine cellar cooling unit problems AL1 tends to arrive with. Answer these at the wine cellar cooling unit before anyone is booked.
All problems
Wine Cellar Too Cold
4 causes, cheapest first
Where AL1 usually leads
Cellar cooling load and room check.
CellarCool
wine cellar cooling units.
Service for CellarCool systems when the wine room drifts warm, turns dry or the unit starts and stops every few minutes.
CellarCool wine cellar cooling unit repairMore CellarCool codes
Temperature and alarms on other makes
Through-the-wall cellar cooling unit
A self-contained box set into an opening in the cellar wall: its cold face blows into the wine room, and its warm face breathes out into the room next door.
Ducted cellar cooling unit
A self-contained cooling unit placed outside the cellar, in a mechanical room, attic or basement, that sends chilled air in and takes return air back through insulated ducts.
Split-system cellar cooling
An evaporator inside or beside the cellar and a condensing unit outside or in another room, joined by an insulated copper line set and charged on site.
In CellarCool's own words
The bottle probe is sensing a temperature that is 4°F below the setpoint
Every code on this site is taken from the manufacturer's documentation, never from a forum or a parts listing. Both CellarCool controller types: the CX through-the-wall controller and the digital controller on Ceiling Mount, split and Ultimate models.
CellarCool AL1 wine cellar cooling unit repair,
where we come out.
The same visit in every metro below: the code, the model number, and a diagnosis before any part is ordered.
All service areasTampa BayFL · 31 areas
Miami / South FloridaFL · 47 areas
New York MetroNY · 75 areas
HoustonTX · 36 areas
ChicagoIL · 50 areas
Los AngelesCA · 95 areas
San DiegoCA · 31 areas
Questions
about AL1.
Can I clear AL1 myself?
Can a CellarCool heat the cellar?
Why would a CellarCool keep cooling below its setpoint?
Is AL1 on a CellarCool CX different?
Back to your everyday
Still showing AL1?
When you book, type the code or the blink count as the controller shows it, add the full model number, and say what the thermometer in the cellar reads now — that gives the technician a head start.
